- Products
PRODUCT RANGE
For 2 decades, we have been at the forefront of producing high-performance electric actuators tailored to a wide array of industries and applications. Our expertise spans heating and air conditioning technology, industrial firing, printing machines, conveyor systems, chlorine dosing systems, heating burners, and many more.
What sets us apart is our in-house gear and gearbox production, enabling us to design actuators that precisely meet our customers’ unique needs while ensuring unmatched quality and reliability. With years of experience in developing customer-specific solutions, we pride ourselves on delivering tailored, innovative results within short turnaround times.
Our control valves, when combined with our high-performance actuators, create a seamless and complete system for industrial applications. Alongside our actuators, we offer an extensive selection of butterfly valves and industrial valves to suit your specific project requirements.
We provide pre-assembled and preset systems, ensuring a hassle-free integration of actuators and butterfly valves or armatures. Already have valves in hand? No problem—we can customize and build the desired actuator directly onto your provided valves.
Have unique requirements? We’re ready to collaborate and develop tailor-made solutions just for you. Contact us today to discuss your project and let us turn your ideas into reality.
Our gearboxes are integral to many other industries and applications. You’ll find our gearboxes powering solutions in conservatory ventilation systems, conveyor technology, and water disinfection systems, to name just a few.
With access to a vast assortment of components, we can efficiently develop customized solutions tailored to your specific needs. Our gearboxes are engineered for durability, performance, and versatility, making them a reliable choice for a wide range of industrial applications.
Discover how our expertise in gearbox manufacturing can enhance your projects. Contact us today for innovative and efficient solutions.
THE MOST POPULAR ACTUATORS
AMONGST THE RANGE PRODUCED ARE AS LISTED BELOW:
Series /Model
ERQT 0815
ERQT 0830
ERQT 1530
ERQT 1560
ERQT 3030
ERQT 3060
Operation Time
15 secs/90°
30 secs/90°
30 secs/90°
60 secs/90°
30 secs/90°
60 secs/90°
Torque
8 Nm
8 Nm
15 Nm
15 Nm
30 Nm
30 Nm
Supply Voltage Option
230VAC OR 110VAC
230VAC OR 110VAC
230VAC OR 110VAC
230VAC OR 110VAC
230VAC OR 110VAC
230VAC OR 110VAC
Peregrine Electric Actuators incorporate the following features
- High Torque, Low Inertia. Short-Circuit proof Synchronous Motors.
- 100% Continuous Electric Duty
- Heavy duty and low maintenance design
- Continuous control times, even with fluctuations in voltage and load
- Instantaneous Start & Stop and reverse
- Robust construction; Pressure Die-Cast Aluminium/Zinc alloy body parts with Epoxy Powder coated finish
- Mounting Position, completely independent of orientation.
- 15 to 80°C Ambient Temperature
- High Quality Hardened & Ground, Carbon Steel Spur gearing for years of trouble-free operation.
- Hardened Stainless-Steel output shaft
- IP65 enclosure protection
- Choice of supply voltages, 230VAC/110VAC or 24VAC. 12VDC & 24VDC available on demand
- Switches with Silver Contacts to ensure millions of operation cycles
- Up to 4 Auxiliary switches possible
- Choice of regular or specially profiled Cams for operation of Auxiliary switches.
- Option with built-in ‘Local Station’ available for AUTO/MANUAL operation
- Up to 2 Potentiometers/ OHMIC feedback possible
- Microprocessor based, “SMART” User Programmable 4-20mA Interface available
- Bearings lubricated for life
- Private branding possible for large batch OEM purchases
Housing & Drive
- Pressure Die – Cast Zinc/ Aluminium Alloy with Epoxy Powder coated finish
- High quality Hardened & Ground Carbon Steel Spur gearing to ensure many years of trouble free operation
- Hardened Stainless Steel output shaft
- Bearings lubricated for life
- 3/2 cable entries
- Available with standard Φ12/15mm x 30 male Shaft or with DIN/ISO5211 Flange (F05/F07 & F10)
- Protection Class IP 65
Potentiometer (Option)
For an external position indication and/ or desired valued comparison
- Up to 2 Potentiometers / Ohmic feedbacks possible
Motor
- Short – circuit proof alternating current synchronous motor
- Single pole reversible
- 230VAC + 10%, 110VAC + 10%, 50/60Hz + 5%, 24VAC + 10%
- Starting and stopping times in milliseconds
- Minimal pulse length of 50-200ms (type dependent)
- Switches with Silver Contacts to ensure millions of operation cycles
- Control steps are 100% maintained
- Insulation Category B in accordance with VDE 0530
Actuation
- By means of manual switch gear
- Via 2 level, 3 level and continuous controller
- Programmable Microprocessor based interface, integrated into the actuator for set values of 0/4 – 20mA
Ambient Temperature
– 15⁰C to 80⁰C
Switching Off
- 2 limit switches (standard)
- All path – dependent switches operated by means of infinitely adjustable control cams
- Exact limitation of end of travel and intermediate positions
Programmable Microprocessor based 0/4-20 mA interface
The programmable Microprocessor based Interface i-CON 1/2 are used for straight forward and accurate positioning of PEREGRINE Electric Actuators. Thanks to a multitude of control options and very simple adjustments, the microprocessor controller suits every area of the industrial application where accurate positioning of the actuator shaft is required.
Installation
Simple Installation by means of solid mounting bracket / ISO flanges
Easy connection to Drive shaft by : – Claw Coupling – Hand Lever Coupling – Lever Arm, Clamping Lever Arm, Ball and Socket Joint, Rods, Spring Rods – Flexible Shaft Coupling – Rigid Shaft Coupling
Options
- 4 additional auxiliary switches
- Microprocessor based Interface – i-CON1 including Potentiometer
- Microprocessor based Interface – i-CON2 including Potentiometer
- Dis-Engageable Hand Lever Coupling for 30 Nm
- Claw coupling for up to 15Nm l ISO Kit for Ball Valves/Butterfly/ Damper Valves
- Mounting Kits for High Temperature applications
- Private Branding possible for large OEMs
Choice of Cams
- Choice of regular or specially profiled cams available
- Can be combined with the Auxiliary switches to provide feedback for complex control logic/models www.peregrinetechnologies.co.in
Onboard Local Station
- Option with onboard Local Station for Auto/Manual operation
- Control accessories – Auxiliary Switches and Potentiometer available as options
